Caraterísticas
Processador:
- Suporta processadoes 10th Gen Intel® Core?, 11th Gen Intel® Core?, Pentium® Gold e Celeron®
- Processor socket LGA1200
- Chipset: Intel® B560 chipset
Memória RAM:
- 4x DDR4 memory slots, support up to 128GB1
- Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel® CPU (by JEDEC & POR)1
- Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel® CPU (by JEDEC & POR)1
- Max overclocking frequency:
- 1DPC 1R Max speed up to 5066 MHz
- 1DPC 2R Max speed up to 4600+ MHz
- 2DPC 1R Max speed up to 4266+ MHz
- 2DPC 2R Max speed up to 4000+ MHz
- Supports Dual-Channel mode
- Supports non-ECC, un-buffered memory
- Supports Intel® Extreme Memory Profile (XMP)
Slots de Expansão:
- 1x PCIe x16 slot
- PCI_E1 (from CPU)
- Support up to PCIe 4.0 for 11th Gen Intel® CPU
- Support up to PCIe 3.0 for 10th Gen Intel® CPU
- 2x PCIe 3.0 x1 slots
- PCI_E2 & PCI_E3 (From B560 chipset)
Áudio:
- Realtek® AL897 Codec
- 7.1-Channel High Definition Audio
- LAN: 1x Realtek® RTL8125B 2.5Gbps LAN controller
Armazenamento:
- 6x SATA 6Gb/s ports (from B560 chipset)
- 2x M.2 slots (Key M)
- M2_1 slot
- Supports up to PCIe 4.0 x4 for 11th Gen Intel® CPU(From CPU)
- Supports up to PCIe 3.0 x4 & SATA 6Gb/s for 10th Gen Intel® CPU (From B560 chipset)1
- Supports 2242/ 2260/ 2280 storage devices
- M2_2 slot2(from B560 chipset)
- Supports up to PCIe 3.0 x4
- Supports SATA up to 6Gb/s
- Supports 2242/ 2260/ 2280 storage devices
- Intel® Optane? Memory Ready1
- Supports Intel® Smart Response Technology for Intel Core? processors
USB:
- Intel® B560 Chipset
- 2x USB 3.2 Gen 2 10Gbps Type-A ports on the back panel
- 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector)
- 2x USB 2.0 Type-A ports on the back panel
- USB Hubs GL850G
- 4x USB 2.0 ports are available through the internal USB 2.0 connectors
Portas I/O Traseiras:
- 1 x PS/2
- 1 x DisplayPort
- 1 x HDMI
- 2 x USB 3.2 Gen 2 10Gbps Type-A
- 2 x USB 3.2 Gen 1 5Gbps Type-A
- 2 x USB 2.0
- 1 x RJ45
- Conectores de áudio
- Dimensões: Formato Micro-ATX, 24.4 cm x 24.4 cm
