Caraterísticas
- Processador: AMD AM4 Socket for AMD Ryzen? 5000 Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series/ 2000 Series/ 2000 G-Series Desktop Processors
- Chipset: AMD X570
Memória RAM:
- 2 x DIMM, Max. 64GB, DDR4 4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3800(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
- 2 x DIMM, Max. 64GB, DDR4 5100(O.C)/4866(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3800(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory *
- AMD RyzenTM 4000 G-Series Processors
- AMD RyzenTM 2000 Series Processors
- 2 x DIMM, Max. 64GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory *
- 2 x DIMM, Max. 64GB, DDR4 3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
- Dual Channel Memory Architecture
Slots de Expansão:
- AMD Ryzen 4000 G-Series / 2000 Series Processors
- AMD Ryzen 5000 Series/ 3000 Series Desktop Processors
- AMD Ryzen 3000 G-Series / 2000 G-Series Processors
- 1 x PCIe 4.0 x16 (x16 mode)
- 1 x PCIe 3.0 x16 (x16 mode)
- 1 x PCIe 3.0 x16 (x8 mode)
Armazenamento:
- AMD RyzenTM 4000 G-Series / 3000 G-Series / 2000 Series / 2000 G-Series Processors :
- AMD Ryzen? 5000 Series/ 3000 Series Desktop Processors :
- 1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support
- AMD X570 chipset:
- 4 x SATA 6Gb/s port(s),
- Support Raid 0, 1, 10
- 1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support
- 1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support
LAN:
- Anti-surge LANGuard
- ROG GameFirst Technology
- Intel® I211-AT
Rede de dados wireless:
- Supports channel bandwidth: HT20/HT40/HT80/HT160
- Intel® Wi-Fi 6 AX200
- 2 x 2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) with MU-MIMO supports dual frequency band 2.4/5GHz
- Up to 2.4Gbps transfer speed
- Bluetooth: Bluetooth® 5.0
- Áudio: upremeFX8-Channel High Definition Audio CODEC S1220A
Portas USB:
- AMD Ryzen? 5000 Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series/ 2000 Series/ 2000 G-Series Desktop Processors :
- 4 x USB 3.2 Gen 2 port(s) (3 x Type-A+1 x Type-C)
- 4 x USB 3.2 Gen 1 port(s) (4 at back panel, blue)
- 2 x USB 2.0 port(s)
- AMD X570 chipset :
- 2 x USB 3.2 Gen 1 port(s) (2 at mid-board)
Portas I/O Painel Traseiro:
- 4 x USB 3.2 Gen 1 (blue)
- 3 x LED-illuminated audio jacks
- 1 x DisplayPort
- 1 x HDMI
- 1 x ASUS Wi-Fi Module
- 3 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A)
- 1 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-C)
- Anti-surge LAN (RJ45) port
- Dimensões: Formato Mini-ITX, 17 cm x 17 cm
